  • SH-TU5

    SH-TU5

    Equivalent with Uniten type 5, with CC Seat or CL seat.

    Shaft size :10-100mm. Pls contact us for technical data



    Operating Limits:



    Temperature:-45to 200

    Pressure:16 bar

    Speed:15m/s

    Axial moment:±1.0mm

    Materials:



    Rotary Ring:Ceramic/SIC/TC

    Stationary Ring: Carbon/SIC/TC/Ceramic/SUS

    Secondary seal:Viton/NBR/EPDM/Aflas/Kalrez etc

    Metal Parts:AISI304/316/Hastelloy/Alloy 20/Monel etc





  • SH-TU2

    SH-TU2

    Equivalent with Uniten type 2, with CC Seat or CL seat.

    Shaft size :10-100mm. Pls contact us for technical data



    Operating Limits:



    Temperature:-35to 180

    Pressure:16 bar

    Speed:15m/s

    Axial moment:±1.0mm

    Materials:



    Rotary Ring:SUC/SIC/TC

    Stationary Ring: Carbon/SIC/TC/Ceramic/SUS

    Secondary seal:Viton/NBR/EPDM/Aflas/Kalrez etc

    Metal Parts:AISI304/316/Hastelloy/Alloy 20/Monel etc

  • SH-TR45

    SH-TR45

    Equivalent with Roten type 45, with CC Seat or CL seat.

    Shaft size :10-150mm. Pls contact us for technical data



    Operating Limits:



    Temperature:10to 200

    Pressure:16 bar

    Speed:15m/s

    Axial moment:±1.0mm

    Materials:



    Rotary Ring:Ceramic/SIC/TC

    Stationary Ring: Carbon/SIC/TC/Ceramic/SUS

    Secondary seal:Viton/NBR/EPDM/Aflas/Kalrez etc

    Metal Parts:AISI304/316/Hastelloy/Alloy 20/Monel etc

  • SH-TR5

    SH-TR5

    Equivalent with Roten type 5, with CC Seat or CL seat.

    Shaft size :10-150mm. Pls contact us for technical data



    Operating Limits:



    Temperature:-45to 200

    Pressure:16 bar

    Speed:15m/s

    Axial moment:±1.0mm

    Materials:



    Rotary Ring:Carbon/SIC/TC

    Stationary Ring: SIC/TC/Ceramic/SUS

    Secondary seal:Viton/NBR/EPDM/Aflas/Kalrez etc

    Metal Parts:AISI304/316/Hastelloy/Alloy 20/Monel etc

  • SH-TR2

    SH-TR2

    Equivalent with Roten type 2, with CC Seat or CL seat.

    Shaft size :6-120mm. Pls contact us for technical data



    Operating Limits:



    Temperature:-35to 180

    Pressure:16 bar

    Speed:15m/s

    Axial moment:±1.0mm

    Materials:



    Rotary Ring:Carbon/SIC/TC

    Stationary Ring: SIC/TC/Ceramic/SUS

    Secondary seal:Viton/NBR/EPDM/Aflas/Kalrez etc

    Metal Parts:AISI304/316/Hastelloy/Alloy 20/Monel etc

  • SH-T82

    SH-T82

    Equivalent with Vulcan type 82,Aesseal type T01DB,Burgmann H12N.

    Shaft size :16-85mm. Pls contact us for technical data



    Operating Limits:



    Temperature:-80to 220

    Pressure:25 bar

    Speed:15m/s

    Axial moment:±1.0mm

    Materials:



    Rotary Ring:Carbon/SIC/TC

    Stationary Ring: SIC/TC/Ceramic/SUS

    Secondary seal:Viton/NBR/EPDM/Aflas/Kalrez etc

    Metal Parts:AISI304/316/Hastelloy/Alloy 20/Monel etc

  • SH-T13DIN

    SH-T13DIN

    Equivalent with Vulcan type 13D,Aesseal type T04D,Burgmann BT-FN.NU, Uniten 3.

    Shaft size :12-40mm. Pls contact us for technical data



    Operating Limits:



    Temperature:-20to 150

    Pressure:10 bar

    Speed:10m/s

    Axial moment:±1.0mm



    Materials:



    Rotary Ring:Ceramic/SIC/TC

    Stationary Ring: Carbon/SIC/TC/Ceramic/SUS

    Secondary seal:Viton/NBR/EPDM/Aflas/Kalrez etc

    Metal Parts:AISI304/316/Hastelloy/Alloy 20/Monel etc

  • SH-T13

    SH-T13

    Equivalent with Vulcan type 13,Aesseal type T04,Burgmann BT-FN, Roten 3.

    Shaft size :10-40mm. Pls contact us for technical data



    Operating Limits:



    Temperature:-20to 150

    Pressure:10 bar

    Speed:10m/s

    Axial moment:±1.0mm



    Materials:



    Rotary Ring:Ceramic/SIC/TC

    Stationary Ring: Carbon/SIC/TC/Ceramic/SUS

    Secondary seal:Viton/NBR/EPDM/Aflas/Kalrez etc

    Metal Parts:AISI304/316/Hastelloy/Alloy 20/Monel etc

  • SH-T2DIN

    SH-T2DIN

    Equivalent with Vulcan type 12 DIN,Aesseal type T03D,Burgmann BT-RN.NU,Floserve 42D, Uniten 2

    Shaft size :10-100mm. Pls contact us for technical data



    Operating Limits:



    Temperature:-40to 200

    Pressure:10 bar

    Speed:15m/s

    Axial moment:±1.0mm



    Materials:



    Rotary Ring:SUS/SIC/TC

    Stationary Ring: CARBON/SIC/TC/Ceramic/SUS

    Secondary seal:Viton/NBR/EPDM/Aflas/Kalrez etc

    Metal Parts:AISI304/316/Hastelloy/Alloy 20/Monel etc

  • SH-T12

    SH-T12

    Equivalent with Vulcan type 12,Aesseal type T03,Burgmann BT-RN,Flowserve type42.Roten type 2.

    Shaft size :10-100mm. Pls contact us for technical data



    Operating Limits:



    Temperature:-40to 200

    Pressure:10 bar

    Speed:15m/s

    Axial moment:±1.0mm



    Materials:



    Rotary Ring:SUS/Carbon/SIC/TC

    Stationary Ring: CAR/SIC/TC

    Secondary seal:Viton/NBR/EPDM/Aflas/Kalrez etc

    Metal Parts:AISI304/316/Hastelloy/Alloy 20/Monel etc

  • SH-T8DIN

    SH-T8DIN

    Equivalent with Vulcan type 8DIN,Aesseal type T01DIN,Burgmann M32.

    Shaft size :10-80mm. Pls contact us for technical data



    Operating Limits:



    Temperature:-30to 200

    Pressure:12 bar

    Speed:20m/s

    Axial moment:±1.0mm



    Materials:



    Rotary Ring:Carbon/SIC/TC

    Stationary Ring: SIC/TC/Ceramic/SUS

    Secondary seal:Viton/NBR/EPDM/Aflas/Kalrez etc

    Metal Parts:AISI304/316/Hastelloy/Alloy 20/Monel etc

  • SH-T8B

    SH-T8B

    Equivalent with Vulcan type 8B,Aesseal type T02,Burgmann M3.

    Shaft size :10-80mm. Pls contact us for technical data



    Operating Limits:



    Temperature:-30to 200

    Pressure:12 bar

    Speed:20m/s

    Axial moment:±1.0mm



    Materials:



    Rotary Ring:Carbon/SIC/TC

    Stationary Ring: SIC/TC/Ceramic/SUS

    Secondary seal:Viton/NBR/EPDM/Aflas/Kalrez etc

    Metal Parts:AISI304/316/Hastelloy/Alloy 20/Monel etc
