mechanical seal - Manufacturers, Factory, Suppliers From China

  • SH-MG97/S1-G28-32mm

    SH-MG97/S1-G28-32mm

    Suit ABS Pumpex submersible pumps.

    P/N:1110173

  • SH-MG97/S2-G60-65mm

    SH-MG97/S2-G60-65mm

    Suit ABS Pumpex submersible pumps.

    P/N:1110173

  • SH-H10/H8

    SH-H10/H8

    Equivalent with Burgmann H10 Seal, Shaft size:15-100mm

    Pls contact us for technical data



    Operating Limits:



    Temperature:-75to 425

    Pressure:25 bar

    Speed:50m/s

    Axial moment:±1.0mm

    Materials:



    Rotary Ring:Carbon/SIC/TC

    Stationary Ring: SIC/TC/Ceramic/SUS

    Secondary seal:Viton/NBR/EPDM/Aflas/Kalrez etc

    Metal Parts:AISI304/316/Hastelloy/Alloy 20/Monel etc/AM350/Inconel 718

  • SH-M891

    SH-M891

    Equivalent with Chesterton 891.shaft size 16-200mm. /0.75-8 inch.Pls contact us for technical data



    Operating Limits:



    Temperature:-30to 205

    Pressure:28 bar

    Speed:15m/s

    Axial moment:±1mm



    Materials:



    Rotary Ring:Carbon/SIC/TC

    Stationary Ring: SIC/TC/Ceramic/SUS

    Secondary seal:Viton/NBR/EPDM/Aflas/Kalrez etc

    Metal Parts:AISI304/316/Hastelloy/Alloy 20/Monel etc/AM350/Inconel 718



  • SH-M7N

    SH-M7N

    Equivalent with Burgmann M7F. Shaft size :14-200mm. Pls contact us for technical data. Other model:M7N/M74N/M78N/M74F/M74S2/



    Operating Limits:



    Temperature:-50to 220

    Pressure:25 bar

    Speed:20m/s

    Axial moment:±1.0mm



    Materials:



    Rotary Ring:Carbon/SIC/TC

    Stationary Ring: SIC/TC/Ceramic/SUS

    Secondary seal:Viton/NBR/EPDM/Aflas/Kalrez etc

    Metal Parts:AISI304/316/Hastelloy/Alloy 20/Monel etc

  • PVDF Products

    PVDF Products

    1. Product details Product/Article: Technical semi-finished product Abbreviated terms: PVDF Material characterisation: Semi crystalline plastic Main components: Polyvinylidene fluoride Components subject to labelling: None Classification according to REACh: Article Notes: - 2. Product characteristics Form/State: Firm Colour: Natural or coloured Odour: Nearly odourless Density: 1,70 – 1,80 g/cm³ (ISO 1183) Melting range: 160°C – 180°C (DSC) Glass transition temperature: - Thermal decomposition...
  • PEEK
  • Mechanical face seal
  • Graphite self-lubricating bearings

    Graphite self-lubricating bearings

    Self-lubricating bearings are divided into composite self-lubricating bearings, solid inlaid self-lubricating bearing shaft, bimetallic materials Self-lubricating bearings, self-lubricating bearings of special materials, according to different purposes and working conditions, different self-lubricating bearings are selected. One big category of solid inlaid self-lubricating bearings  is a kind of novel lubricating bearings with both the characteristics of metal bearings and oil-free lubricati...
  • Elastic Spider

    Elastic Spider

    Description:Elastic Spider  is suitable for all hub machines. It is also the recommended elastomer  insert  for all applications in general engineer ring /Hydraul ics   Advantage: -Extremely resistant to wear, oil, ozone and ageing, also resistant with hydrolysis(ideal for tropical climeates) -Protect the drive against dynamic overload. -Good physical properties -Wide range of application -failure protection -Easy installation   Technical Data Opertating condition: Temperature:-35℃ ...
  • CrO coating shaft
  • Bearing Isolators
