  • SH-H10/H8

    SH-H10/H8

    Equivalent with Burgmann H10 Seal, Shaft size:15-100mm

    Pls contact us for technical data



    Operating Limits:



    Temperature:-75to 425

    Pressure:25 bar

    Speed:50m/s

    Axial moment:±1.0mm

    Materials:



    Rotary Ring:Carbon/SIC/TC

    Stationary Ring: SIC/TC/Ceramic/SUS

    Secondary seal:Viton/NBR/EPDM/Aflas/Kalrez etc

    Metal Parts:AISI304/316/Hastelloy/Alloy 20/Monel etc/AM350/Inconel 718

  • SH-M9

    SH-M9

    Equivalent with John Crane type 9.Shaft size :0.5-6 inch. Pls contact us for technical data



    Operating Limits:



    Temperature:-212to 400

    Pressure:24 bar

    Speed:25m/s

    Axial moment:±1mm



    Materials:



    Rotary Ring:Carbon/SIC/TC

    Stationary Ring: SIC/TC/Ceramic/SUS

    Secondary seal:Viton/NBR/EPDM/Aflas/Kalrez etc

    Metal Parts:AISI304/316/Hastelloy/Alloy 20/Monel etc/AM350/Inconel 718

  • SH-M891

    SH-M891

    Equivalent with Chesterton 891.shaft size 16-200mm. /0.75-8 inch.Pls contact us for technical data



    Operating Limits:



    Temperature:-30to 205

    Pressure:28 bar

    Speed:15m/s

    Axial moment:±1mm



    Materials:



    Rotary Ring:Carbon/SIC/TC

    Stationary Ring: SIC/TC/Ceramic/SUS

    Secondary seal:Viton/NBR/EPDM/Aflas/Kalrez etc

    Metal Parts:AISI304/316/Hastelloy/Alloy 20/Monel etc/AM350/Inconel 718



  • SH-VAR-C

    SH-VAR-C

    Equivalent with Flowserve VAR type seal ,Shaft size:1-7 inch,  Pls contact us for technical data



    Operating Limits:



    Temperature:-50to 205

    Pressure:13 bar

    Speed:15m/s

    Axial moment:±1mm



    Materials:



    Rotary Ring:Carbon/SIC/TC

    Stationary Ring: SIC/TC/Ceramic/SUS

    Secondary seal:Viton/NBR/EPDM/Aflas/Kalrez etc

    Metal Parts:AISI304/316/Hastelloy/Alloy 20/Monel etc/AM350/Inconel 718

  • SH-SRAO-55

    SH-SRAO-55

    Equivalent with Pillar seal

    Shaft size:55mm

    Pls contact us for technical data

  • SH-SAI

    SH-SAI

    Equivalent with AESSEAL SAI,Shaft size:18-100mm. Pls contact us for technical data



    Operating Limits:



    Temperature:-50to 205

    Pressure:12 bar

    Speed:15m/s

    Axial moment:±1mm



    Materials:



    Rotary Ring:Carbon/SIC/TC

    Stationary Ring: SIC/TC/Ceramic/SUS

    Secondary seal:Viton/NBR/EPDM/Aflas/Kalrez etc

    Metal Parts:AISI304/316/Hastelloy/Alloy 20/Monel etc/AM350/Inconel 718

  • SH-RO-B

    SH-RO-B

    Equivalent with Flowserve RO seal,Shaft size:20-100mm .Pls contact us for technical data

    Operating Limits:



    Temperature:-30to 205

    Pressure:10 bar

    Speed:15m/s

    Axial moment:±1mm



    Materials:



    Rotary Ring:Carbon/SIC/TC

    Stationary Ring: SIC/TC/Ceramic/SUS

    Secondary seal:Viton/NBR/EPDM/Aflas/Kalrez etc

    Metal Parts:AISI304/316/Hastelloy/Alloy 20/Monel etc/AM350/Inconel 718

  • SH-RO-A

    SH-RO-A

    Equivalent with Flowserve RO seal,Shaft size:20-100mm .Pls contact us for technical data

    Operating Limits:



    Temperature:-30to 205

    Pressure:10 bar

    Speed:15m/s

    Axial moment:±1mm



    Materials:



    Rotary Ring:Carbon/SIC/TC

    Stationary Ring: SIC/TC/Ceramic/SUS

    Secondary seal:Viton/NBR/EPDM/Aflas/Kalrez etc

    Metal Parts:AISI304/316/Hastelloy/Alloy 20/Monel etc/AM350/Inconel 718

  • SH-MY40

    SH-MY40

    According to drawing of clientShaft size:0.625-3 inch. Pls contact us for technical data

    Operating Limits:



    Temperature:-30to 205

    Pressure:8 bar

    Speed:10m/s

    Axial moment:±1mm



    Materials:



    Rotary Ring:Carbon/SIC/TC

    Stationary Ring: SIC/TC/Ceramic/SUS

    Secondary seal:Viton/NBR/EPDM/Aflas/Kalrez etc

    Metal Parts:AISI304/316/Hastelloy/Alloy 20/Monel etc/AM350/Inconel 718

  • SH-MD100

    SH-MD100

    Equivalent with Flowserve MD100 Seal. Pls contact us for technical data

  • SH-M921U

    SH-M921U

    Equivalent with GPM GLRD seal. Pls contact us for technical data

  • SH-M606

    SH-M606

    According to drawing of client. Pls contact us for technical data
